Overview

Magnifico MRI

The next generation Open MRI from Esaote

The technological evolution in MRI of the last years has seen important developments particularly in data acquisition and elaboration resulting in a substantial improvement in image quality and reduction of scan-times.

Today, the majority of MRI installations are about outcome-based services that not only address specific clinical needs, but also operational and financial demands.

This is the strength of Esaote's Magnifico, which incorporates latest MRI technology for uncompromised diagnostic quality, combined with a permanent magnet that guarantees low operating costs.

Magnifico MRI

Patient positioning and comfort

Magnifico MRI Open system, free coil positioning, laser alignment, split coil design, transparent headcoil, easy-access patient bed. It all adds up to make patient positioning easy, fast and comfortable.

Magnifico MRI head coil

Claustrophobic patients

Magnifico is the right system for claustrophobic patients. The open magnet simply makes it a comfortable MRI experience for all patients, in particular children. Additionally, Magnifico comes with a transparent headcoil for enhanced patient comfort.

True-Motion

Several pathologies are affected by the motion of a joint like e.g. impingement. In these cases, Esaote's True-Motion MRI offers a complementary approach to standard static MRI with dynamic real-time acquisition of the joint in motion.

An additional tool to improve patient care in particular in high-level sports medicine.

Magnifico MRI

Post-surgical imaging

Patients with metal implants are an ever-increasing part of the MRI population. Magnifico MRI is an optimal solution as the system has an intrinsic low level of susceptibility for metal with respect to traditional MRI.

Together with the dedicated MAR sequences, Magnifico offers high quality diagnostics also in the presence of the majority of implants.

Magnifico MRI head coil

Ease of use

Esaote systems have the reputation of being very easy to use and Magnifico is in line with this standard with a user interface focused on getting the work done without losing the flexibility to customize scans whenever needed.

Magnifico MRI head coil

Examination workflow

Simplified workflow and Protocol driven scanning for fast exams and high throughput without comprising diagnostic quality.

When result counts

Ample selection of dedicated coils for an optimal result and excellent patient experience. The multichannel design allows for a high SNR, high signal homogeneity and therefore high spatial resolution.

The outcome is what is important: diagnostic quality.

Magnifico MRI coils

Technology and features are system/configuration dependent. Specifications subject to change without notice. Information might refer to products or modalities not yet approved in all countries. Product images are for illustrative purposes only. For further details, please contact your Esaote sales representative.

Features Insight

Magnifico, magnify your possibilities

Maintenance-free open permanent magnet
0.4 Tesla field strength
Stand-alone system with small foot-print
Power Consumption less than 3 kW single phase 220/110V power outlet
Ergonomic open patient table with patient weight of up to 200 kg (440 lb)
Complete set of dedicated optimized coils
Full range of imaging sequences comprising Steady State Sequences, various Fat Saturation techniques, contrast media imaging.
High resolution with slices of up to 0,3 mm in isotropic 3D
Ease of use: Full set of pre-defined sequences and protocols

Magnifico MRI features

Magnifico intuitive User Interface

Based on Window type interface®, Magnifico is easy to learn and use with a user interface and protocols designed for high quality imaging. Thanks to the preset protocols, exams are fast and simple to perform.

Expert users can personalize all scanning parameters and customer sequences can be stored and integrated in the normal menu structure for subsequent use.

Magnifico comprises a complete software package: supplied with an extensive range of tools to process, display and analyze images.

Magnifico MRI

Easy Patient Access

Easy patient access is one of the features that distinguishes Magnifico as an ideal system for more advanced applications such as MRI arthrography. The wide opening and compact magnet provide easy access to the patient.

Magnifico MRI Connectivity

Connectivity and Integration

Magnifico includes complete networking and storage features to work either stand alone or as part of an integrated environment.

Data security

Magnifico is in line with today’s requirements for data security with automatic antivirus security updates.

Standalone operation

As a stand-alone scanner, Magnifico comprises an integrated DVD storage and retrieve software package, printer output facility and a patient-CD package.

Network operation

Magnifico is DICOM and IHS compliant and offers smart solutions for connectivity to your PACS and teleradiology.

Siting

Magnifico MRI system siting

Magnifico MRI: Siting

Thanks to its smart design the magnet unit and RF shielding will fit in a space of 20 m² (212 sq.ft.).

Example of a typical installation.

Please contact your local representative for a personalized design for your site.

Power requirements

Power consumption: 0.5 kW in Unit OFF (thermal control); maximum 2.4 kW in acquisition mode.
Power supply from a single phase 220/110V power outlet

Economics

Compelling economics

Magnifico has been developed in line with the Esaote MRI philosophy which means quality MRI at reduced costs:

Compact installation
Easy operation
Low running costs

Low running costs

Magnifico MRI

Power consumption: 0.5 kW in Unit OFF (thermal control); maximum 2.4 kW in acquisition mode.
No cryogens, no water cooling
Dedicated service contracts

Service

All Esaote systems come with remote service capability. Many system parameters and system components can be checked via the remote service program specially developed for Esaote MRI systems. The remote service capability allows Esaote to react to any potential issue and to get you up and running faster!

Upgrades

Esaote MRI systems are built for the future. With an average life cycle for an MRI system of about 11 years, being able to keep up with technology advances is important to satisfy market needs.

Video

Esaote North America installed the first Magnifico^™ Open MRI system

Esaote North America, Inc. is excited to show the first installation of the Magnifico^™ Open MRI system at the Sport Ortho Urgent Care clinic in Murfreesboro, TN. Inspired by customers and designed for the user, the Magnifico^™ Open bridges the gap between traditional musculoskeletal and whole-body imaging. “We chose the Magnifico^™ Open from Esaote because it offered the best option for our clinic size. The small footprint allows us to get a great magnet that produces excellent images and offers our patients a streamlined continuity of care all in one place,” says Brant Bell, MSM, PA-C, Founder/VP of Clinical Services, Sport Ortho Urgent Care.

Magnifico: The next generation Open MRI from Esaote

Magnifico is based on Esaote’s long-term experience and success in MRI, which is predominantly due to a strong focus on customer needs. With Magnifico, Esaote has created a customer driven MRI where technology is applied to serve user needs in terms of diagnostic efficacy and cost per exam. Thanks to the Esaote MRI technology, clinicians can broaden their perspective without compromising on workflow, image quality, ease-of-use or patient comfort. Our open whole-body system is the right choice for those who want to go the extra mile without losing momentum.

Open up to new cutting-edge innovations

Our amazing journey is coming to an end with the third and final live streaming event, in which we will introduce new MRI technologies dedicated to the medical and healthcare fields. After addressing the themes ‘Research’ and ‘Experience’, this launch event will focus on ‘Challenge’. Yet another and certainly not the last challenge taken on by Esaote - which was the first company to develop dedicated MRI systems. Esaote has constantly expanded its product portfolio - developing dedicated systems for spine and joint imaging, as well as unique technologies, such as the tilting MR which enables clinicians to conduct weight-bearing MR studies of the anatomy. Now, Esaote will introduce a new open total body MRI.

e-shop

Esaote E-shop

Stop just imaging it.

Accessories & spare-parts for MRI systems

If it’s a Magnetic Resonance Imaging accessory, coils, printer, component or software, you don’t need to image it anymore: you will find it here. Register to E-shop to access the full catalogue, place an order, chat with our experts. Literally: whatever.

ENTER Esaote E-shop -SHOP

Docs & Operator Manuals

Magnifico: The next generation Open MRI from Esaote

Connectivity

Magnifico: Connectivity and Integration

Full DICOM Connectivity And Sophisticated Storage Functionality, Including Dicom Worklist.
Remote Service Capability.

Windows® interface: Because it's based on Windows® Magnifico is easy to learn and use. With a user interface and protocols are custom designed custom design for spine and extremities MRI, exam are fast and simple to perform.

Connectivity: Magnifico comes with comprehensive network, archiving and documentation features to work either as a stand-alone system or as part of an integrated environment. It offers an integrated DVD archive and retrieve software package, printer capability and a patient CD package. Magnifico is also DICOM compliant with connectivity and teleradiology solutions.

Remote operations: All Esaote MRI systems come with remote service capability. Many system parameters and components can be checked using the specially developed remote software, so Esaote’s application specialists can check image quality and assist local operators to set exam parameters. In case service is required, reduced reaction and repair times help you remain productive.
